Our products are supported by a fully secure management application & dashboard parallel hosted, both on and off-site, for complete reliability. As Brightspace learns more about your asset and its occupant’s behaviour further efficiency is gained over time.

With a minimally disruptive integration process, assets can be upgraded without interfering with day-to-day operations.

Occupant tracking and environmental monitoring allow external systems, new or old, to serve the precise demands of a space. Additional filtration and UV-C treatment can reduce ventilation requirements and infection risk while improving air quality and hygiene.

A complementary range designed to scale effortlessly.

OCC-010
Occupant Tracker

  • Track individual occupants with a high degree of accuracy including movement paths, physical location & quantity

  • With a privacy-first design, our products cannot collect or transmit identifying information.

  • Up to 200 Square meters depending on installation height.

  • Simple ceiling or pendant mount installation, each unit requires a power source located within 1.5 meters.

    Devices connect over Wirepas mesh removing the need for additional data cables or integration with existing IT infrastructure.

  • Connected with BMS systems or control discreet equipment autonomously through the Brightspace Gateway Integrator using most major communication protocols.

EVM-005
Environmental Monitor

  • Accurately monitor 12 major air quality metrics including CO2, TVOC’s, PM2.5 and report in real-time

  • Track additional metrics including light level & sound pressure

  • Monitors are deployed every 250 square meters or one per room depending on the use case.

  • Simple wall mount installation, each unit requires a power source located within 1.5 meters.

    Devices connect over Wirepas mesh removing the need for additional data cables or integration with existing IT infrastructure.

  • Connected with BMS systems or control discreet equipment autonomously through the Brightspace Gateway Integrator using most major communication protocols.

GWB-002
Gateway Integrator

  • Each gateway can cover 1- 3 floors depending on construction style with a recommended 50 Brightspace products per gateway.

    At least one Brightspace device should be installed within 50 meters of each gateway.

  • Brightspace uses a proprietary 2.4GHz self-healing mesh network to connect all edge devices to the gateway and ensure maximum uptime in the event of a single device failure.

    This network allows edge devices to connect to core Brightspace systems throughout a deployment without relying on existing infrastructure in multiple tendencies.

  • Connect to BMS and other building systems with ease, this includes individual Modbus and BACnet controlled devices.

  • Ensure continuous operation by identifying unit faults and service requirements such as filter replacements.

  • Power the automation of your facilities via BrightSpace’s Edge AI facilities management software to drastically reduce energy consumption

STB-001
Steribright Filtration

  • 60 - 100 Square meters depending on installation height and eACH requirements

  • Intelligent operation to ensure spaces are only treated where and when needed based on the requirements of the occupants.

    360° radar detects occupant presence with an extremely high degree of accuracy to ensure surface operation only takes place when a space is vacated and immediately reverts if the occupant returns during a cycle.

  • Operates in symphony with the rest of the Brightspace range to deliver proportionate eACH to the space and its occupant’s requirements.

    Sound pressure sensors adjust delivery to maximise audible comfort and efficiency.

    Occupant-aware air filtration and sterilisation.

    Untreated air undergoes a sequence of filtration stages, starting with a G2 pre-filter, followed by either a MERV 13, MERV 14 or HEPA 13 filtration followed by activated carbon filtration.

    Finally, the air also passes through a reaction chamber where it is exposed to UV-C to eliminate any remaining microorganisms and reduce odour.

  • Automated, scheduled, or on-demand sterilisation of spaces using UV-C.

  • Accurately monitor 10 air quality metrics including CO2, TVOC's PM2.5 and reporting

  • Air filters are monitored with differential pressure sensors to ensure efficacy and inform service intervals.

    Filters are electronically tagged to ensure a properly specified filter in installed in each unit.

  • Easy Installation

    Simple recessed, surface or pendant ceiling mount installation to suit any deployment.

    Each unit requires a power source located within 1.5 meters.

    Devices connect over Brightspace’s proprietary mesh network removing the need for additional data cables or integration with existing IT infrastructure.

  • Connected with BMS systems or control discreet equipment autonomously through the Brightspace Gateway Integrator using most major communication protocols.

ARB-011
Aerobright Filtration

  • 60 - 100 Square meters depending on installation height and eACH requirements

  • Operates in symphony with the rest of the Brightspace range to deliver proportionate eACH to the space and its occupants requirements

    Sound pressure sensors adjust delivery to maximise audible comfort and efficiency

  • Occupancy-aware air filtration and sterilisation.

    Untreated air undergoes a sequence of filtration stages, starting with a G2 pre-filter, followed by either a MERV 13, MERV 14 or HEPA 13 filtration followed by activated carbon filtration.

  • Air filters are monitored with differential pressure sensors to ensure efficacy and inform service intervals.

    Filters are electronically tagged to ensure a properly specified filter in installed in each unit.

  • Simple recessed, surface or pendant ceiling mount installation to suit any deployment.

    Each unit requires a power source located within 1.5 meters.

    Devices connect over Brightspace’s proprietary mesh network removing the need for additional data cables or integration with existing IT infrastructure.

  • Connected with BMS systems or control discreet equipment autonomously through the Brightspace Gateway Integrator using most major communication protocols.
